Battery Powered Portable Methane Detector For Natural Flammable Gas ODM

  • 1
  • 2
  • 3

Delivery Time : 5-7 Work Days

Supply Ability : 100 Units Per Month

Power Supply : Rechargeable lithium-ion battery

Alarm Type : Audible visual alarms

Model Number : G10E

Payment Terms : T/T

Detection Range : 0~100%VOl(Methane)

Packaging Details : 38*33*18cm 4.5kg

Place of Origin : Shandong,China

Target Gas : Methane (CH4)

Weight : Approximately 1.1 kg

Battery Life : Up to 10 hours continuous use

Humidity Range : 0-98% RH (non-condensing)

Operating Temperature : -20°C to 50°C

Product Name : Portable Laser Methane Detector

Response Time : < 0.1 seconds

Dimensions : 208mm x 78mm x 53mm

Display : LCD digital display

Certification : ATEX

MOQ : 1

Brand Name : AiLF

Detection Method : Laser Absorption Spectrum

Price : $12000~$15000

Data Logging : Supports data storage and USB download

Enclosure Protection Class : IP66

Contact Now

Portable TDLAS Laser Natural Gas Methane Leak Detector Real-Time Analysis Fast Response with Probe

Description:

Portable Laser Gas Detector provides better detection performance and long service life that traditional equipment don't have; Combined with mature sampling methods by a trolley or a probe, it makes leak detection rapider and more accurate.

With the built-in gas reference, the G10 portable laser gas detector unit can continuously self-calibrate during operation to ensure accurate detection.

Full-range detection supports readings of concentration in ppm, % LEL and %VOL.

Equipped with the gas pump with a higher flow and efficient filtering system, G10 can be mounted on a trolley or an electric bicycle.

These portable laser methane detectors employ a principle called “Tunable Diode Laser Absorption Spectroscopy” (TDLAS) to detect methane. A laser beam is emitted at a specific wavelength, which interacts with methane molecules in the target area. Methane absorbs light at certain wavelengths, allowing the detector to measure the intensity of the absorbed light. The absorbed light intensity is then correlated to the methane concentration in the sampled area.

Battery Powered Portable Methane Detector For Natural Flammable Gas ODM
Model G10 Detection Subject Methane(CH4)
Measuring Principle Laser Absorption Spectrum Display Unit PPM,%LEL,%VOL
Resolution 0.5 ppm Explosion-Proof Grade ATEX Exib IIC T4 Gb
Response Time 0.1 s Operating Temperature -20 ~ 50 ºC
Concentration Range 0~100% VOL Operating Humidity < 98%RH, no condensation
Enclosure Protection Class IP66 Main Unit Dimension 208 x 78 x 53 mm
Power supply and Endurance Lithium battery >10h Main Unit Weight 1.1 kg
Accessories Strap, hand-held probe Optional Accessories Bell-shaped probe,trolley


Key features and benefits:
High Sensitivity:
TDLAS-based detectors can achieve 0.5ppm-level sensitivity, allowing for the detection of even small leaks.
Specificity:
This TDLAS based laser methane detector can enabling accurate leak identification with fast response time at 0.1s.
Real-time Monitoring:
TDLAS allows for real-time measurements, providing immediate feedback on methane values.
Versatility:
They can be used in various applications, including leak detection in pipelines, industrial facilities, and landfills.


Examples of applications:
Natural Gas Leak Detection:
Identifying leaks in pipelines, storage tanks, and other natural gas infrastructure.
Industrial Monitoring:
Detecting leaks in chemical plants, refineries, and other industrial facilities.
Environmental Monitoring:
Measuring ethane emissions from various sources, including landfills and agricultural activities.
Battery Powered Portable Methane Detector For Natural Flammable Gas ODM

Battery Powered Portable Methane Detector For Natural Flammable Gas ODM

Battery Powered Portable Methane Detector For Natural Flammable Gas ODM
Battery Powered Portable Methane Detector For Natural Flammable Gas ODM
Battery Powered Portable Methane Detector For Natural Flammable Gas ODM
